Multi-Channel HEVC Decoder
HC32000D
The best answer to deliver sporting events with high density of 4K x 2ch/HD x 8ch decoding in 1RU.
Inquiries about Digital Video System SolutionsKey features
- Supports H.265/HEVC H.264/AVC HDTV/SDTV Decoding
Up to 2 x 4K ch/8 x HD ch decoding in combination with HC32000 encoder. The perfect density always available for any transmission, such as sporting events, live events and news gathering. - Supports BISS-1, BISS-2/CA of encryption Industry standard format
Supports BISS-2/CA which is the latest scrambling protocol to guaranteed the highest security of the stream. - Selectable audio formats and maximum 32ch discrete audio performance
Supports maximum 32ch audio to support multi-language transmission. MPEG-1 LayerII and AAC (at 2ch video encoding only) as an encoding format, and SMPTE302M and DolbyE pass though are supported. - Seamless Protection Switching
Complementing packet losses in 2 lines IP transmission for each other. - Dual Power Supply
Built in Dual Power supply.
Rear Panel
- GENLOCK
- SDI-A
- SDI-C
- SDI-B
- SDI-D
- ASI1
- ASI2
- CTRL1
- CTRL2
- DATA1
- DATA2
- AC inlet1
- AC inlet2
Specifications
Video
| Output Interface | BNC : 3G-SDI(SMPTE ST 424) / HD-SDI(SMPTE ST 292) | |
|---|---|---|
| Decode Method | H.265/HEVC | H.264/MPEG-4 |
| Profile ; Level | Profile : Main 4:2:2 10, Main 10, Main ; Level : 5.1 | Profile : High4:2:2, High10, High, Main ; Level : 4.2, 4.1, 4.0, 3.2, 3.0 |
| Video Format @ Frame Rate | 2160P(3840x2160)@ 50Hz, 59.94Hz ; max.2PES 1080P(1920x1080)@ 50Hz, 59.94Hz ; max.6PES 1080I(1920x1080)@ 25Hz, 29.97Hz ; max.8PES |
1080I(1920/1440x1080)@25Hz, 29.97Hz ; max.2PES |
Audio
| Output Interface | Embedded Audio 16ch(SMPTE ST 299) | ||
|---|---|---|---|
| Decode Method | MPEG-2 AAC-LC : 1ch(1/0), 2ch(1+1), 2ch(2/0), 4ch(3/1), 5.1ch(3/2/1), 6ch(2/2/2); max.8PES MPEG-4 AAC-LC : 2ch(2/0), 4ch(3/1), 5.1ch(3/2/1); max.8PES MPEG-4 HE-AACv1 : 2ch(2/0), 5.1ch(3/2/1); max.4PES MPEG-4 AAC-ELD : 2ch(2/0), 4ch(3/1), 5.1ch(3/2/1); max.4PES |
||
Ancillary
| Data Format | SMPTE ST 2038 (at 2ch video decoding, 1PES/TS) | ||
|---|---|---|---|
Transport Stream(TS)
| Input Interface | DVB-ASI : BNCx2(0.8Vp-p 75Ω) | |
|---|---|---|
| Input Type | MPEG-2 TS(188/204byte) | |
| Maximum Number of TS | 2TS | |
| Maximum TS Rate (Per 1TS) | 200.000Mbps | |
| TS Decryption OP1 | BISS-2 1/E/CA, BISS-1 1/E | |
| TS over IP |
Input Interface | 100BASE-TX/1000BASE-T(RJ-45) x4 |
| Network Features | IPv4 : IGMPv2/v3, IPv6: MLDv2 | |
| Transmission | RTP/UDP/IP(SMPTE2022-2-2007, RFC2250, RFC3550, RFC1889), Unicast/Multicast | |
| Error Correction | FEC(SMPTE2022-1-2007 / Pro-MPEG COP#3 R2), ARQ | |
| Other | Seamless Protection | |
Control
| Local Control | LCD(20digits x4/brightness control available) + Front Switch(7 buttons) x2 |
|---|---|
| Network Interface | 100BASE-TX/1000BASE-T(RJ-45) x4 |
| Remote Control | Web GUI, SNMP v1, Ping, Syslog |
Others
| Dimensions | W : 433 x H : 44 x D : 430(mm) (w/o Connector, Foot, Rack mount bracket) |
|---|---|
| Weight | 8kg typ. |
| Supply Voltage | AC100V to 240V, 50/60Hz (Dual power supply for redundancy) |
| Power Consumption | 300W max. |
| Operating Environment | 0 to 45℃, 30 to 90% (non condensing) |
| Compliance | RoHS, VCCI, FCC, ICES, CE, UL, CSA |
Option
| Suffix | Option Name | Description | |
|---|---|---|---|
| Software | OP1 | HC3x000D_OP_BISS2 | BISS-2/-1 Decryption |
| OP2 | HC3x000D_OP_SEAMLESS | Seamless Protection |
